Galaxy Power System GPS4827
60
The bottom line(s) show:
An Hourglass may appear in the lower left hand corner of the screen.
This indicates that a configuration change is being saved to non-
volatile memory.
Audible Alarm Cutoff State(Toggle)
(Only shown if an alarm is active)
Plant Mode (Default Float)
Screen information is updated approximately every two seconds. The front panel
display offers a series of menus that allow the user to:
Configure
Control
View Status
View History
View Statistics
Perform Diagnostics
These menu operations are accomplished by navigating through different screens.
