Network Cable
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable
EIA/TIA-568 100-ohm (100m)
100Base-TX: 2-pair UTP/STP Cat. 5 cable
EIA/TIA-568 100-ohm (100m)
Optical cable
 SC (Multi-mode): 50/125um or 62.5/125um
 SC (Single mode): 9/125um
 Available distance: 2KM (Multi-mode) /
30KM (single-mode)
 Wavelength: 1310nm (multi-mode/ single
mode)
Back-plane 1.6Gbps
Packet throughput
ability
1.19Mpps @64bytes
Power Supply
12 ~48 VDC
Redundant power with polarity reverse protects
function and connective removable terminal
block for master and slave power.
Power
consumption
7.68 Watts
X-Ring
2 ports for X-Ring to provide redundant backup
feature and the recovery time below 300ms and
start by Web interface management. The ring
port can be defined by Web interface.
VLAN
Port based VLAN
IEEE802.1Q Tag VLAN.
Both of port based and Tag based VLAN group
up to 64 VLANs.
