Rate Control Interface
[NOTE]
1. If the configuration is not saved, it will be lost when the switch is
powered off.
2. QoS and Rate control cannot exist at the same.
System Log
Set up system log events and view the system log events
System Log
Use to view the system events.
 Click
Reload button to get newest system log event
 To clear the log events, click
Clear
 Drag down the page list to switch to a different page.
 System Log Client Mode: Select Client Only, Server Only, or Both
 System Log Server IP: Assign the system log server IP
 Click
Apply
