DIP-switch
The nine position DIP-switch is used to configure the relay alarm ring
master mode. The default value for each position is OFF. Software
configuration is also required for the alarm relay. The alarm relay contacts
are normally open.
DIP Switch No Status Description
1
OFF Disable port 1 Alarm
ON Enable port 1 Alarm.
2
OFF Disable port 2 Alarm
ON Enable port 2 Alarm.
3
OFF Disable port 3 Alarm
ON Enable port 3 Alarm.
4
OFF Disable port 4 Alarm
ON Enable port 4 Alarm.
5
OFF Disable port 5 Alarm
ON Enable port 5 Alarm.
6 OFF Disable port 6 Alarm
