9. External Connections
An adapter cable is included with the SPP-100 to convert the 25-pin
output connector into a standard D-25 female connector as shown in the
figure below.
D-25 Female
11
8
13
12
10
9
7
6
5
4
3
1
2
14
15
16
17
18
19
20
21
22
23
24
25
nAutoFd ( nDStr b)
nFault ( Us e r De fi ne d 2)
nI ni t ( nI ni t)
nSe le ctI n ( nAStr b)
Si gnal Gr ound
Si gnal Gr ound
Si gnal Gr ound
Si gnal Gr ound
Si gnal Gr ound
Si gnal Gr ound
Si gnal Gr ound
Si gnal Gr ound
( nWr i te ) nStr obe
( AD1) Data1
( AD2) Data2
( AD3) Data3
( AD4) Data4
( AD5) Data5
( AD6) Data6
( AD7) Data7
( AD8) Data8
( I ntr ) nAck
( nWait) Bus y
( Us e r De fi ne d 1) PEr r or
( Us e r De fi ne d 3) nSe le ct
NOTES:
1.
Si gnal nam e s i n p are nthe s e s r e p r e s e nt EPP nam i ng conve nti on.
2. Si gnal nam e s be gi nni ng w i th ' n' i nd icate low -acti ve s i gnals .
Figure 21. Connector Signal Assignment
