6. Several predefined Basic Configurations have been included
allowing easy selection of different configurations that match
standard printer port settings (see table below).
EPP Variable 3
Standard Variable 2
Standard 278H 1
Standard 378H 0
Port
Mode
I/O
Address
Basic
Configuration
Figure 13a. Windows 2000 Basic Configurations Table
Revision E (Refer to back of PCMCIA Card)
None Standard Variable 9
Variable Standard Variable 8
None EPP Variable 7
None EPP 278 6
None EPP 378 5
Variable EPP Variable 4
Variable EPP 278 3
Variable EPP 378 2
5 EPP 278 1
7 EPP 378 0
IRQ Port
Mode
I/O
Address
Basic
Configuratio
n
Figure 13b. Windows 2000 Basic Configurations Table
Revision E2 and later (Refer to back of PCMCIA Card)
None EPP 378 5
Variable EPP 378 4
None EPP 278 3
Variable EPP 278 2
None EPP Variable 1
Variable EPP Variable 0
IRQ Port
Mode
I/O
Address
Basic
Configuratio
n
Figure 13c. Windows XP Basic Configurations Table
Revision E2 and later (Refer to back of PCMCIA Card)
When selecting a basic configuration from the "Setting based on
list" pay attention to the Conflicting device list information. Try to
select a configuration that displays "No conflicts". If resource
