3. Double click the device group Ports (Com and LPT) . The
SPP-100 device name should appear in the list of adapters.
4. Click the SPP-100's device name and then click the Properties
button to open a Port Properties box for this hardware adapter.
5. Click the Resources tab located along the top of the properties
box.
Figure 5. SPP-100 Resource Allocations in Windows 95/98/ME
6. Several predefined Basic Configurations have been included
allowing easy selection of different configurations that match
standard printer port settings (see table below).
EPP Variable 3
Standard Variable 2
Standard 278H 1
Standard 378H 0
Port
Mode
I/O
Address
Basic
Configuration
Figure 6a. Windows 95/98/ME Basic Configurations Table
Revision E (Refer to back of PCMCIA Card)
3-4 Quatech Inc.
