new hardware type found. If no INF files are found, click the
Browse button and search the Win95 sub directory on the
installation diskette. The user is not required to select the file
name. When the directory containing the INF files is located,
Windows 95/98/ME will automatically select the correct file.
5. The SPP-100 parallel port requires two drivers supplied by
Microsoft on the Windows 95/98/ME CD or diskettes:
LPT.VXD
and LPTENUM.VXD. If these files do not already
exist on the system, the user will be prompted to insert the
Windows 95/98/ME CD or installation diskettes. If prompted
to do so, insert the necessary CD or diskettes and click
OK .
IMPORTANT NOTE:
If the user already has these files installed on the
computer, or if the installation disks are unavailable, it
may not be necessary to supply the computer with the
Windows 95 CD or installation diskettes. If prompted for
the disks, click
OK . A dialog box with an option to skip
will appear. Click the Skip button and the files will not
be installed. If these files exist in the windows system
directory, those files will be used.
6. Windows 95/98/ME socket services should indicate the
SPP-100 PCMCIA card configuration by a low-high tone beep.
7. A System Settings Change dialog box should open up. To
assure that Windows 95/98/ME properly assigns the SPP-100 a
logical printer port number (LPT2, etc.), you must restart your
computer with the SPP-100 installed. Click the
Yes button to
restart your computer now. Do not remove the SPP-100 from
the PCMCIA socket during the restart process
The SPP-100 PC Card should now be configured. Windows 95/98/ME
automatically enumerates the SPP-100 to the first available LPT port
number. For additional configuration information, consult the "SPP-100
Resource Settings" section of this document. In the future, Windows
95/98/ME will automatically recognize and configure the SPP-100 in this
default configuration.
3-2 Quatech Inc.
