B&B Electronics SPP-100 - Manual - Manual (Page 25)

None Standard Variable 9
Variable Standard Variable 8
None EPP Variable 7
None EPP 278 6
None EPP 378 5
Variable EPP Variable 4
Variable EPP 278 3
Variable EPP 378 2
5 EPP 278 1
7 EPP 378 0
IRQ Port
Mode
I/O
Address
Basic
Configuratio
n
Figure 6b. Windows 95/98/ME Basic Configurations Table
Revision E2 and later (Refer to back of PCMCIA Card)
When selecting a basic configuration from the "Setting based on
list" pay attention to the Conflicting device list information. Try to
select a configuration that displays "No conflicts". If resource
conflicts can be resolved by switching to one of the predefined
basic configurations then skip down to the last step.
7. To modify any of the system resource showing a conflict click
the resource name and click the Change Setting button. An Edit
Resource window will open up. Note that the I/O address
resources for basic configurations 0 and 1 are not allowed to be
changed.
SPP-100 User's Manual 3-5
