DS2165/DS2165Q
041295 2/17
OVERVIEW
The DS2165 contains three major functional blocks: a
high performance (10 MIPS) DSP engine, two indepen-
dent PCM interfaces (X and Y) which connect directly to
serial Time Division Multiplexed (TDM) backplanes, and
a serial port that can configure the device on-the-fly via
an external controller. A 10 MHz master clock is re-
quired by the DSP engine. The DS2165 can be confi-
gured to perform either two expansions, two compres-
sions, or one expansion and one compression. The
PCM/ADPCM data interfaces support data rates from
256 KHz to 4.096 MHz. Typically, the PCM data rates
will be 1.544 MHz for
µ
-law and 2.048 MHz for A-law.
Each channel on the device samples the serial input
PCM or ADPCM bit stream during a user-programmed
input time slot, processes the data and outputs the re-
sult during a user-programmed output time slot.
Each PCM interface has a control register which speci-
fies functional characteristics (compress, expand, by-
pass, and idle), data format (
µ -law or A-law), and algo-
rithm reset control. With the SPS pin strapped high, the
software mode is enabled and the serial port can be
used to configure the device. In this mode, a novel ad-
dressing scheme allows multiple devices to share a
common 3-wire control bus, simplifying system-level in-
terconnect.
With SPS low, the hardware mode is enabled. This
mode disables the serial port and maps certain control
register bits to some of the address and serial port pins.
Under the hardware mode, no external host controller is
required and all PCM/ADPCM input and output time
slots default to time slot 0.
HARDWARE RESET
RST allows the user to reset both channel algorithms
and the contents of the internal registers. This pin must
be held low for at least 1 ms on system power-up after
the master clock is stable to ensure that that the device
has initialized properly. RST should also be asserted
when changing to or from the hardware mode. RST
clears all bits of the Control Register for both channels
except the IPD bits; the IPD bits for both channels are
set to 1.
SOFTWARE MODE
Tying SPS high enables the software mode. In this
mode, an external host controller writes configuration
data to the DS2165 via the serial port through inputs
SCLK, SDI, and CS. (See Figure 2.) Each write to the
DS2165 is either a 2-byte write or a 4-byte write. A 2-
byte write consists of the Address/Command Byte
(ACB), followed by a byte to configure the Control Reg-
ister (CR) for either the X or Y channel. The 4-byte write
consists of the ACB, followed by a byte to configure the
CR, and then one byte to set the input time slot and
another byte to set the output time slot.
ADDRESS/COMMAND BYTE
In the software mode, the address/command byte is the
first byte written to the serial port; it identifies which of
the 64 possible ADPCM processors sharing the port
wiring is to be updated. Address data must match that at
inputs A0 to A5. If no match occurs, the device ignores
the following configuration data. If an address match oc-
curs, the next three bytes written are accepted as con-
trol, input and output time slot data. Bit ACB.6 deter-
mines which side (X or Y) of the device is to be updated.
The PCM and ADPCM outputs are tristated during reg-
ister updates.
CONTROL REGISTER
The control register establishes idle, algorithm reset,
bypass, data format and channel coding for the selected
channel.
The X and Y side PCM interfaces can be independently
disabled (output 3-stated) via IPD. When IPD is set for
both channels, the device enters a low-power standby
mode. In this mode, the serial port must not be operated
faster than 39 KHz.
ALRST resets the algorithm coefficients for the selected
channel to their initial values. ALRST will be cleared by
the device when the algorithm reset is complete.
