DS2165/DS2165Q
041295 12/17
ABSOLUTE MAXIMUM RATINGS*
Voltage on any Pin Relative to Ground
-1.0V to +7.0V
Operating Temperature
0
°
C to 70
°
C
Storage Temperature
-55
°
C to +125
°
C
Soldering Temperature
260
°
C for 10 seconds
* This is a stress rating only and functional operation of the device at these or any other conditions above
those indicated in the operation sections of this specification is not implied. Exposure to absolute maxi-
mum rating conditions for extended periods of time may affect reliability.
RECOMMENDED DC OPERATING CONDITIONS
(0
°
C to 70
°
C)
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
NOTES
Logic 1
V
IH
2.0
V
CC
+0.3
V
5
Logic 0
V
IL
-0.3
+0.8
V
5
Supply
V
DD
4.5
5.5
V
5
Logic 1
V
IH
2.2
V
CC
+0.3
V
6
Logic 0
V
IL
-0.3
+0.4
V
6
Supply
V
DD
2.7
3.6
V
6
CAPACITANCE
(t
A
=25
°
C)
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
NOTES
Input Capacitance
C
IN
5
pF
Output Capacitance
C
OUT
10
pF
(0
°
C to 70
°
C; V
DD
=5V + 10%)
DC ELECTRICAL CHARACTERISTICS
(V
DD
=3.0V + 20% – 10% for DS2165QL)
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
NOTES
Active Supply Current
I
DDA
20
mA
1, 2, 5
Active Supply Current
I
DDA
12
mA
1, 2, 6
Idle Supply Current
I
DDPD
1
mA
1, 2 ,3
Input Leakage
I
I
-1.0
+1.0
µ
A
Output Leakage
I
O
-1.0
+1.0
µ
A
4
Output Current (2.4V)
I
OH
-1.0
mA
5
Output Current (0.4V)
I
OL
+4.0
mA
5
Output Current (2.2V)
I
OH
-0.5
mA
6
Output Current (0.4V)
I
OL
+2.0
mA
6
NOTES:
1. CLKX = CLKY = 1.544 MHz; MCLK = 10 MHz.
2. Outputs open; inputs swinging full supply levels.
3. Both channels in idle mode.
4. XOUT and YOUT are 3-stated.
5. Applies only to 5V device.
6. Applies only to 3V device (DS2165QL).
