5 PACKAGE
MECHANICAL
DIMENSIONS
The target package is a 27x27 mm 400-lead TE
-CSBGA with ball pitch of 1.27mm for all port density
configuration.
6 POWER
ESTIMATE
Current typical power estimate is 2.7 Watts at 3.3V (pending mode of operation).
1
TE-CSBGA: Thermally Enhanced Chip Scale Ball Grid Array
