164
ATtiny2313
2543A–AVR–08/03
Table 71. Pin Values Used to Enter Programming Mode
Pin Symbol Value
XA1 Prog_enable[3] 0
XA0 Prog_enable[2] 0
BS1 Prog_enable[1] 0
WR Prog_enable[0] 0
Table 72. XA1 and XA0 Coding
XA1 XA0 Action when XTAL1 is Pulsed
0 0 Load Flash or EEPROM Address (High or low address byte
determined by BS1).
0 1 Load Data (High or Low data byte for Flash determined by BS1).
1 0 Load Command
1 1 No Action, Idle
Table 73. Command Byte Bit Coding
Command Byte Command Executed
1000 0000 Chip Erase
0100 0000 Write Fuse bits
0010 0000 Write Lock bits
0001 0000 Write Flash
0001 0001 Write EEPROM
0000 1000 Read Signature Bytes and Calibration byte
0000 0100 Read Fuse and Lock bits
0000 0010 Read Flash
0000 0011 Read EEPROM
Table 74. No. of Words in a Page and No. of Pages in the Flash
Flash Size Page Size PCWORD No. of Pages PCPAGE PCMSB
1K words (2K bytes) 16 words PC[3:0] 64 PC[9:4] 9
Table 75. No. of Words in a Page and No. of Pages in the EEPROM
EEPROM Size Page Size PCWORD No. of Pages PCPAGE EEAMSB
128 bytes 4 bytes EEA[1:0] 32 EEA[6:2] 6
