MAX7034
315MHz/434MHz ASK Superheterodyne
Receiver
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(
Typical Application Circuit, V
DD5
= +4.5V to +5.5V, no RF signal applied. T
A
= -40°C to +125°C, unless otherwise noted. Typical val-
ues are at V
DD5
= +5.0V and T
A
= +25°C, unless otherwise noted.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
DD5
to AGND.......................................................-0.3V to +6.0V
AV
DD
to AGND ......................................................-0.3V to +4.0V
DV
DD
to DGND......................................................-0.3V to +4.0V
AGND to DGND.....................................................-0.1V to +0.1V
IRSEL, DATAOUT, XTALSEL,
SHDN, EN_REG to AGND ....................-0.3V to (V
DD5
+ 0.3V)
All Other Pins to AGND............................-0.3V to (DV
DD
+ 0.3V)
Continuous Power Dissipation (T
A
= +70°C)
28-Pin TSSOP (derate 12.8mW/°C above +70°C) ..1025.6mW
Operating Temperature Range .........................-40°C to +125°C
Storage Temperature Range .............................-65°C to +150°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
V
DD5
+5.0V nominal supply voltage
4.5
5.0
5.5
V
f
RF
= 315MHz
6.7
8.2
Supply Current
I
DD
V
SHDN
= V
DD5
f
RF
= 434MHz
7.2
8.7
mA
Shutdown Supply Current
I
SHDN
V
SHDN
= 0V
3
8
µA
Input-Voltage Low
V
IL
0.4
V
EN_REG, SHDN
V
DD5
-
0.4
Input-Voltage High
V
IH
XTALSEL
D V
D D
-
0.4
V
Input Logic Current High
I
IH
15
µA
f
RF
= 434MHz, V
IRSEL
= D V
D D
D V
D D
-
0.4
f
RF
= 375MHz, V
IRSEL
= D V
D D
/2
1.1
D V
D D
-
1.5
Image-Reject Select Voltage
(Note 2)
f
RF
= 315MHz, V
IRSEL
= 0V
0.4
V
DATAOUT Output-Voltage Low
V
OL
I
SINK
= 10µA
0.125
V
DATAOUT Output-Voltage High
V
OH
I
SOURCE
= 10µA
V
D D 5
-
0.125
V
