Taurus 3 User’s Manual - Appendices
Page 57
Taurus 3 User’s Manual - Appendices
Appendix E - Specifications
Type:
Programmable monophonic analog
bass synthesizer w/52 presets
Synth Engine:
Oscillator Section:
Oscillators A & B:
Octave: 32’, 16’, 8’
Wave: Sawtooth
Oscillator B Frequency Offset:
-1 octave to +1 octave
Glide Rate: 0 to 0.5 sec
Level: Osc A/B Mix (100/0 to 0/100%)
Volume Envelope:
Attack Time: 5 to 560 msec
Decay Time: 50 msec to 2.8 sec
Sustain Level: 0 to 100%
Filter Section:
Type: -24dB/oct Low Pass
Cutoff: 20Hz to 20KHz
Resonance: 0 to Self-oscillation
Filter Env. Amount: 0 to 100%
Filter Envelope:
Attack Time: 5 to 56 msec
Decay Time: 50 msec to 2.8 sec
Modulation Section:
LFO Rate: 0.1 Hz to 100 Hz
Waveform: Triangle, Square, Ramp,
Sawtooth
Destination: Pitch, Filter
Amount: 0 to 100%
Pedalboard:
13 keys (C-C)
Transmits polyphonic MIDI Note On/Off
with velocity
Performance Controls:
Control Footwheel w/LED bargraph display
Volume Footwheel
Footswitches: Glide, Decay, Octave, Bank,
Presets (4), Transpose/PGM
User Interface:
LCD Display, 2 x 16 characters
Mode switches:
Master
Preset
Selection/Navigation controls:
Cursor
Store
Value encoder (with pushswitch)
Side Panel:
AC Power Inlet (universal power supply,
100-250 VAC, 50-60 Hz,
power consumption: 15 Watts)
Power ON/OFF
Audio Output (2)
Control Voltage Inputs:
Pitch CV: 0 to + 5V
Filter CV: 0 to +5V
Volume CV: 0 to +5V
Keyboard Gate: +5V trigger
MIDI In, Out
USB
Outputs:
Monophonic Hi Z Out
Monophonic Lo Z Out
Dimensions:
24.5” x 23.5” x 8.75”
(622 mm x 597 mm x 222 mm)
Weight:
45 lb (20.4 kg)
Operating System;
Flash upgradeable via MIDI SysEx
Specifications subject to change without notice
