Taurus 3 User’s Manual - The User Interface
Page 39
Taurus 3 User’s Manual - The User Interface
MIDI SETUP (con’t)
Allows you to select the routing of the MIDI Merge function for the USB
input. When MIDI Merge is ON, the T3 will echo all MIDI data received
at the USB MIDI Input port to the selected MIDI Output port, merged
with any MIDI data generated by the T3. This allows you to pass MIDI
data thru the T3, even though the T3 has no dedicated MIDI Thru con-
nector. To change the selected MIDI output port, use the CURSOR to
highlight the output parameter, then use the VALUE knob to select the
desired output.
Values: NONE, DIN OUT, USB OUT, DIN/USB OUT;
the default is NONE.
Allows you to select the MIDI output connection (None, DIN, USB or
both). To specify the MIDI output connection, use the CURSOR button
to highlight the output selection, then use the VALUE knob to select the
new output.
Values: NONE, DIN, USB, DIN/USB; the default is DIN/USB
NOTE: When using MIDI Merge, take precautions to insure that you
do not create a MIDI feedback loop (where the output is passed back
into the input and then merged with the output again). A feedback loop
can result in unwanted side effects, like a locked-up T3. If this should
this occur, cycling the power should resolve the condition.
Allows you to select the routing of the MIDI Merge function for the DIN
input. When MIDI Merge is ON, the T3 will echo all MIDI data received
at the MIDI DIN Input port to the selected MIDI Output port, merged
with any MIDI data generated by the T3. To change the selected MIDI
output port, use the CURSOR to highlight the output parameter, then
use the VALUE knob to select the desired output.
Values: NONE, DIN OUT, USB OUT, DIN/USB OUT;
the default is NONE.
MIDI MERGE DIN INPUT:
MIDI OUTPUT:
MIDI MERGE USB INPUT:
