Taurus 3 User’s Manual - The User Interface
Page 49
Taurus 3 User’s Manual - The User Interface
CALIBRATION (con’t)
CONTROL WHEEL:
The last menu in the System Utilities menu allows you to enable or
disable reception of Firmware Updates. The default is OFF. The OFF
state protects the Taurus from inadvertently entering a Firmware Update
cycle.
FIRMWARE UPGRADE ENABLE/DISABLE:
Allows you to calibrate the CONTROL Footwheel. Press STORE to
access the CONTROL Footwheel calibration menu.
You will be asked if you wish to proceed. Use the VALUE knob to select
YES or NO. If you are uncertain, or if you change your mind about
performing this calibration, select ‘NO’ and press STORE, and you will
return to the System Utilities Calibration menu. To proceed with the
calibration, you should first move the CONTROL footwheel to the
middle position, then select ‘YES’ and press STORE.
The Control Wheel calibration menu will appear. To calibrate, move the
CONTROL footwheel to the maximum position (UP) and minimum
(DN) positions.
As you move the footwheel, the display will update the maximum and
minimum values. To complete the calibration, press STORE. You will be
returned to the Calibration menu.
NOTE: If this calibration is done incorrectly, the footwheel may not operate normally. If this
should this happen, try recalibrating the footwheel again using the procedure above.
