Taurus 3 User’s Manual - The User Interface
Page 51
Taurus 3 User’s Manual - The User Interface
SECTION CONTROL FUNCTION CC VALUE/RANGE
Footwheels
CONTROL
Adjusts the active parameter. The MIDI CC
parameter transmitted by the CONTROL
footwheel depends on the active parameter
that is being modified.
Varies 0 – 127
VOLUME Adjusts the output volume 7 0 – 127
Interface
Panel
MASTER Master mode switch - -
PRESET Preset mode switch - -
CURSOR Navigation control - -
STORE Data entry/store control - -
Oscillator
B FREQ Adjusts the coarse offset frequency of Oscillator B MSB 10
LSB 42
0 - 127
BEAT Adjusts the fine offset frequency of Oscillator B MSB 11
LSB 43
0 – 127
GLIDE Sets the portamento rate time MSB 5
LSB 37
0 – 127
OCTAVE Selects the octave setting of the oscillators 74 42 (LO)
85 (MED)
127 (HI)
MIX Adjusts the balance (mix) of Oscillators A & B MSB 15
LSB 47
0 – 127
ATTACK Adjusts the volume envelope attack time MSB 28
LSB 60
0 – 127
SUSTAIN Sets the volume envelope sustain level MSB 30
LSB 62
0 – 127
DECAY Adjusts the volume envelope decay time MSB 29
LSB 61
0 – 127
LFO
LFO RATE/CLOCK Adjusts the LFO frequency/clock divider MSB 3
LSB 35
0 – 127
FILTER Adjusts the Filter modulation amount MSB 6
LSB 38
0 – 127
PITCH Adjusts the Oscillator modulation amount MSB 8
LSB 40
0 – 127
MODWHEEL Adjusts combined Filter and Oscillator amounts MSB 1
LSB 33
0 – 127
SYNC Sets the LFO sync mode 102 42 (OFF)
85 (KY)
127 (MIDI)
SQUARE Selects the LFO Square Wave 68 31
TRIANGLE Selects the LFO Triangle Wave 68 63
RAMP Selects the LFO Ramp Wave 68 95
SAW Selects the LFO Sawtooth Wave 68 127
Taurus 3 MIDI CC messages
