Taurus 3 User’s Manual - The Components
Page 15
Taurus 3 User’s Manual - The Components
LFO SYNC (OFF, KB, MIDI)
Selects the sync options for the LFO. A setting of ‘OFF’ means that the LFO is free-running. A setting of
‘KB’ will cause the LFO to be restarted from 0 degrees every time a pedal is depressed (this means 0V
for the Triangle and Ramp waveforms, and the top of the Square and Sawtooth waveforms). When LFO
SYNC is set to ‘MIDI’, the LFO RATE parameter becomes a MIDI clock divider offering 20 different time
value options as shown in the table below. The divisor is based on 24 clocks per quarter note (the MIDI
standard). Note that if no MIDI clock is present when LFO SYNC is set to ‘MIDI’, the LFO will run at
the rate stored in the Preset for the free-running condition, but divided by the clock divider setting.
Additional CV control:
The FILTER jack on the side-panel is a CV input for external control of the filter cutoff parameter. The
jack accepts 0 to +5 volts, or an expression pedal like the Moog EP-2. A voltage applied to this jack is
added to the setting of the filter cutoff control. A one volt change in the control voltage will change the
cutoff frequency of the filter by about one octave.
LFO Panel Controls (con’t):
CLOCKS/ NOTE TIME VALUE LFO CLOCK
DIVIDER
MIDI CC VALUES
2 1/32 note triplet /32T 122 – 127
3 1/32 note /32 116 – 121
4 1/16 note triplet /16T 109 – 115
6 1/16 note /16 103 – 108
8 1/8 note triplet /8 T 097 – 102
9 Dotted 1/16 note /16D 090 – 096
12 1/8 note /8 084 – 089
16 Quarter note triplet /4 T 077 – 083
18 Dotted 1/8 note /8 D 071 – 076
24 Quarter note /4 065 – 070
32 Half note triplet /2 T 058 – 064
36 Dotted quarter note /4 D 052 – 057
48 Half note /2 045 – 051
64 Whole note triplet WH T 039 – 044
72 Dotted half note /2 D 033 – 038
96 Whole note WH 026 – 032
144 Dotted Whole note WH D 020 – 025
192 2 Whole notes 2 WH 013 – 019
288 3 Whole notes 3 WH 007 – 012
384 4 Whole notes 4 WH 000 – 006
When LFO SYNC is set to ‘MIDI’, the LFO RATE parameter becomes
a MIDI clock divider that can be programmed to one of 20 (21) dif-
ferent values. The divisor is based on 24 clocks per quarter note (the
MIDI standard). The table below shows how the number of MIDI clocks
relates to musical time values. The default clock divider value is “/4” (24
clocks/quarter note)
.
