Taurus 3 User’s Manual - The User Interface
Page 51
Taurus 3 User’s Manual - The User Interface
How the Taurus 3 handles MIDI
When you adjust any one of the Taurus 3 panel controls, MIDI Continuous Controller (CC) messages
are transmitted to the MIDI Output. The information contained in these MIDI messages varies accord-
ing to the selected parameter. For example, when GLIDE is selected as the active parameter, rotating
the VALUE encoder or adjusting the CONTROL Footwheel generates MIDI CC data corresponding to
the Glide Rate parameter (CC#5).
The chart on the following pages list the default MIDI CC data that is generated for each front panel
control.
NOTE:
1. Many of the T3 parameters support high resolution, 14-bit MIDI CC messages,
which allow for finer control and smoother changes when the T3 is controlled
from a sequencer or DAW. For these high resolution parameters, the MSB
indicates the ‘regular’ CC number, and the LSB indicates the high-resolution
‘fine’ control value. If you are only sending 7-bit MIDI CC messages to control
these parameters, use the MSB channel number by itself.
2. For the T3 to transmit 14 bit MIDI CC messages, the ‘14-Bit’ parameter
(Master Menu/MIDI Setup) must be set to ‘ON’ :
