Taurus 3 User’s Manual - The User Interface
Page 47
Taurus 3 User’s Manual - The User Interface
NOTE: All calibration procedures should be thoroughly reviewed before proceeding. Observe the
following precautions and recommendations before attempting any calibration operation.
1. The T3 must be at a stable and constant temperature during calibration. You should allow a warm
up period of at least 5 minutes before beginning any calibrations.
2. The Note Calibration procedure takes up to 30 minutes to cover the MIDI note range of 0 - 60. If
you are performing this calibration, allow sufficient time for the calibration process to complete.
3. The T3 is calibrated at the factory. The Note Calibration operation is not necessary unless the T3
goes out of tune.
4. You can exit out of a calibration at any time by pressing the MASTER button. For the Note
Calibration operation, only those notes that have already been calibrated will be saved. The remaining
notes will revert to their previous calibration values. Interrupting the Note Calibration operation in this
manner may result in inaccurate tuning.
5. Note Calibration is not meant for overall tuning drifts, such as if the T3 is just 10 cents sharp. Use
the FINE TUNE control to adjust for small tuning drifts as needed.
Allows you to calibrate the Taurus 3. The calibration utilities allow you
to perform individual calibrations on the VOLUME and CONTROL
Footwheels and the Note Range. For example, the Note Calibration
operation individually tunes each note exactly for each oscillator and
octave setting. This tuning information is stored in the T3 EEPROM and
referenced when playing a note to guarantee that the oscillators will
be in tune. These individual calibrations ensure that the T3 performs
predictably and precisely. To access the calibration options, press STORE,
then use the VALUE knob to select the desired calibration.
CALIBRATION:
