52 PNEG-545 100 Series Portable Dryer
4. Dryer Electrical Conduits
Upper Junction Box, Top Auger Motor Conduit and
Operator Light Parts List (See Figure 4E)
REF # PART # DESCRIPTION
1 D03-0057 CONDUIT 1/2" EMT METALLIC
2 D03-0054 CONNECTOR 1/2" EMT COMPRESSION
3 HH-1096 CLAMP 1/2" CONDUIT
4 D03-0075 CONNECTOR 1/2" EMT TO SEALTITE
5 120-1538-4 SEALTITE PVC 1/2"
6 006-1377-1 ELBOW 1/2" 90° PVC WITH
7 D03-0117 LAMP 90° W/JUNC. BOX
8 D03-0575 BULB, 100W 130V ROUGH SERVICE
9 FH-6972 ENCLOSURE 4 x 4 x 2.5 WHITE PVC
10 FH-1310 CONNECTOR 1/2"
11 WR-182SJOWA WIRE 18/2 TYPE SJOW-A BLACK
12 D01-0358 MOUNTING PLATE WELDMENT, TILT. BX
13 D03-0010-DC TILT SWITCH 6° 6" LEADS
14 SPD-2098 CLIP TILT SWITCH
15 D01-0103 TILT SWITCH SHAFT
