PNEG-545 100 Series Portable Dryer
3. Fan/Heaters
36'' Fan/Heater LP Pipe Train Assembly Parts List
REF #
PART #
DESCRIPTION
36" LP F/H
1
THH-4120
ELBOW, 3/4"-90° SCH 40
1
2
THH-4121
NIPPLE, 3/4" CLOSE SCH 40
2
3
007-1048-3
BALL VALVE, 3/4" W/LEVER HANDLE
1
4
THH-4125
NIPPLE, 3/4" x 2 SCH 40
2
5
THH-4154
TEE, 3/4" x 3/4" x 1/4" SCH 40
1
6
HH-2984
GAUGE, PRESSURE 0-30# LP
1
7
THH-4136
NIPPLE, 3/4" x 3" SCH 40
1
8
056-2223-8
VALVE, SOLENOID 3/4" NPT 115V DIN
1
9
056-2228-7
VALVE, SOLENOID 3/4" NPT 115V BYP
1
10
THH-4066
ELBOW 3/4-90° STREET SCH 40
1
11
THH-4149
ELBOW, 3/4"-1/2" REDUCER SCH 40
1
12
HH-2029
NIPPLE, 1/2" x 1-1/2" SCH 40
2
13
HH-1453
TEE, 1/2" x 1/2" x 1/2" SCH 40
1
14
HH-7013
SWITCH SCREW-IN VAPOR HIGH-LIMIT
1
15
THH-4071
ELBOW 1/2"-90° SCH 40
1
16
TFC-0023-50
REGULATOR, 1/2" NPT 50 PSI
1
17
D07-0019
NIPPLE, 1/2" x 1-1/2" SCH 80
2
18
031-1008-7
PRESSURE RELIEF VALVE 300 PSI
1
19
HH-4846
TEE, 1/2" x 1/2" x 1/4" SCH 80
1
20
HH-1251
STRAINER, 1/2" “Y” SCH 80
1
21
HH-1932
ELBOW, 1/2" PIPE - 1/2" FLARE BRASS
1
22
TFC-0095
HOSE, 1/2" x 24" LP GAS
2
23
TF-1227
PIPE TRAIN BRACKET FOR 36 AND 42"
1
24
326-1047-9
U-BOLT 5/16"-18 x 1-3/8" x 2-3/16"
3
25
401-5503-8
PLUMBING MOUNTING BRACKET
1
26
401-5255-5
PLUMBING MOUNTING BASE BRACKET
1
27
HH-4847
ELBOW, 1/2"-90° SCH 80
2
28
D01-2217
VAPORIZER SUPPORT PLATE BLACK
1
29
410-1783-1-B
VAPORIZER ADJUSTING WELDMENT 1/2"
1
REF #
PART #
DESCRIPTION
ORIFICE
SIZE
*
CD-0150
ORIFICE FOR 36" FANS W/15 HP MOTORS
.328"
* NOT SHOWN
