1. Main Structure Assembly
PNEG-545 100 Series Portable Dryer 25
Top Auger with Wet Bin Assembly Parts List
and
REF #
PART #
DESCRIPTION
QTY
108T
112
114
116
118
120
122
126
1
D01-1521
WET BIN SIDE, 4' SIDE GALV. PERF
4
4
2
4
2
4
1
D01-1522
WET BIN SIDE, 6' SIDE GALV. PERF
4
2
4
6
4
6
6
2
D01-0103
MERCURY SWITCH SHAFT
1
1
1
1
1
1
1
1
3
D21-0003
TOP EDGE ANGLE 71.875"
4
2
2
3
D31-0004
TOP EDGE ANGLE 95.875"
2
2
4
2
4
4
3
D01-0168
TOP EDGE ANGLE 119.875"
2
4
2
3a
D31-0003
TOP EDGE ANGLE SPLICE
2
2
2
2
2
4
4
5
D01-0156
CHANNEL-TOP AUGER HOUSING
2
2
2
2
2
2
2
2
6
D01-0167
MERCURY SWITCH PADDLE WELDMENT
1
1
1
1
1
1
1
1
7
D01-0811
AUGER TOP WELDMENT 8' BASKET
1
7
D21-0015
AUGER TOP FRONT WELDMENT
1
1
1
7
D01-0608
AUGER TOP FRONT WELDMENT 16' BASKET
1
7
D31-0091
AUGER TOP FRONT WELDMENT
1
1
1
7
D01-0801
AUGER TOP/BOT REAR WELDMENT 12' BASKET
1
7
D31-0267
AUGER TOP AND BOTTOM WELDMENT
1
1
1
2
2
7
D61-0184
AUGER WELDMENT 117-7/8"
1
8
D01-0148
TOP AUGER HOUSING HINGE R.H.
2
2
2
2
2
2
2
2
8a
D01-0147
TOP AUGER HOUSING HINGE L.H.
2
2
2
2
2
2
2
2
9
D01-1525
WET BIN END
2
2
2
2
2
2
2
2
10
D21-0002
TOP AUGER TROUGH SIDE/6'
2
2
10
D31-0010
TOP AUGER TROUGH SIDE/8'
2
2
4
2
4
4
10
D01-0161
TOP AUGER TROUGH SIDE/10'
2
4
2
11
D01-1650
REAR AUGER BEARING COVER
1
1
1
1
1
1
1
1
12
D31-0028
TOP AUGER HOUSING END
2
2
2
2
2
2
2
2
13
D32-0001
BEARING 1-1/2" DIA W/FLANGETTE
2
2
2
2
2
2
2
2
14
D31-0090
SHAFT, TOP AUGER FRONT (WITH KEYWAY)
1
1
1
1
1
1
1
1
14a
D31-0005
SHAFT, TOP AUGER STUB REAR
1
1
1
1
1
1
1
1
15
D01-1123
TOP AUGER COVER, 30.25"
1
1
1
1
1
1
1
1
15
D01-1124
TOP AUGER COVER, 24.25"
2
2
3
4
5
7
5
7
15
D01-1125
TOP AUGER COVER, 20.25"
2
2
2
2
2
4
4
16
D31-0015
TOP AUGER BEARING SUPPORT
1
1
1
1
1
2
2
17
D31-0011
CENTER STABILIZER BEAM
1
1
1
1
1
2
2
18
D31-0009
GUSSET ATTACH BRACKET
2
2
2
2
2
4
4
19
D31-0001
CENTER HAND RAIL GUSSET L.H.
2
2
2
2
2
4
4
20
D31-0002
CENTER HAND RAIL GUSSET R.H.
2
2
2
2
2
4
4
21
D21-0001-Y
HAND RAIL SUPPORT, 1" EMT x 71.75"
4
2
2
21
D31-0006-Y
HAND RAIL SUPPORT, 1" EMT x 95.75"
2
4
2
4
4
21
D01-0151-Y
HAND RAIL, 1" EMT x 119.75" LONG
2
2
4
2
22
D01-0140
HANGER BRACKET - HANDRAIL GALV.
8
16
16
16
16
16
24
24
23
D31-0008
TOP AUGER TROUGH SPLICE
2
2
2
2
2
4
4
24
D01-1245
TOP AUGER BEARING HANGER ASSEMBLY
1
1
1
1
1
2
2
25
D31-0076
SHAFT, AUGER SPLICE
1
1
1
1
1
2
2
