PNEG-545 100 Series Portable Dryer
1. Main Structure Assembly
Frame, Auger Trough, Hopper Bulkheads and Metering
Rolls Parts List
The part number list above covers all parts pointed out on
and
REF #
PART #
DESCRIPTION
QTY
108T
112
114
116
118
120
122
126
1
D01-1136Y
PLENUM CLOSURE DOOR ANGLE, R.H.
3
5
6
7
8
9
10
12
2
D01-1136X
PLENUM CLOSURE DOOR ANGLE, L.H.
4
6
7
8
9
10
11
13
3
D01-0109
HOPPER BULKHEAD
6
10
12
14
16
18
20
24
4
D01-0004
GUSSET PLATE
10
14
16
18
20
22
24
28
5
D01-0005
SIDE LEG
6
8
10
12
14
16
16
20
6
D01-0007
CORNER LEG
4
6
6
6
6
6
8
8
7
D01-0011
HITCH BRACKET, L.H.
1
1
1
1
1
1
1
1
8
D01-0012
HITCH BRACKET, R.H.
1
1
1
1
1
1
1
1
9
D01-0008
FRONT AND REAR FRAME TIE CHANNEL
2
4
4
4
4
4
6
6
10
D01-2435
BOTTOM AUGER BEARING PLATE
1
1
1
1
1
1
1
1
11
D11-0005
FRAME RAIL, 8' RIGHT
1
11
D51-0002
FRAME RAIL, 12' RIGHT
1
11
D21-0011
FRAME RAIL, 14' RIGHT
1
11
D01-0538
FRAME RAIL, 16' RIGHT
1
11
D31-0044
FRAME RAIL, 18' RIGHT
1
11
D61-0002
FRAME RAIL, 20' RIGHT
1
11
D101-0002
FRAME RAIL, 22' RIGHT
1
11
D71-0001
FRAME RAIL, 26' RIGHT
1
11a
D11-0004
FRAME RAIL, 8' LEFT
1
11a
D51-0001
FRAME RAIL, 12' LEFT
1
11a
D21-0010
FRAME RAIL, 14' LEFT
1
11a
D01-0537
FRAME RAIL, 16' LEFT
1
11a
D31-0043
FRAME RAIL, 18' LEFT
1
11a
D61-0001
FRAME RAIL, 20' LEFT
1
11a
D101-0001
FRAME RAIL, 22' LEFT
1
11a
D71-0002
FRAME RAIL, 26' LEFT
1
12
D01-0048
TROUGH PANEL
8
12
14
16
18
20
22
26
13
D01-1512
PLATE, CROSS CHANNEL SEAL W/TABS
N/A
1
1
1
1
1
2
2
14
D01-1291
HANGER BEARING “C” CHANNEL
N/A
1
1
1
1
1
2
2
15
D01-1290
HANGER BEARING “J” PLATE
N/A
2
2
2
2
2
4
4
16
D02-0028
CLEVIS PIN 5/16" x 1-3/4"
16
24
32
32
40
40
48
56
17
D31-0148
METER ROLL WASHER
8
12
16
16
20
20
24
28
18
D02-0061
METER ROLL SUPPORT BEARING
2
4
6
6
8
8
10
12
19
D01-0177
SUPPORT STRAP
4
6
7
8
9
10
11
13
20
D01-1511
PLATE, END CHANNEL SEAL W/TAB
2
2
2
2
2
2
2
2
21
D01-2434
DISCHARGE PLATE
1
1
1
1
1
1
1
1
22
D31-0031
METER ROLL, FRONT
4
4
2
4
2
4
2
2
23
D31-0030
METER ROLL, INTERMEDIATE
2
4
4
6
6
8
10
24
D31-0029
METER ROLL, REAR
2
2
2
2
