PNEG-545 100 Series Portable Dryer
3. Fan/Heaters
40'' and 42'' LP Pipe Train Assembly Parts List
REF #
PART #
DESCRIPTION
40 AND 42'' LP F/H
W/15 AND 20 HP
MOTORS
40 AND 42'' LP F/H
W/ 25 HP AND LARGER
MOTORS
1
THH-4115
ELBOW, 1"-90° SCH 40
2
2
2
007-1104-4
NIPPLE, CLOSE 1"
4
4
3
007-1296-8
BALL VALVE, 1" WITH LEVER HANDLE
1
1
4
007-1106-9
TEE, 1" x 1" x 3/4"
1
1
5
D07-0027
REDUCER, 3/4"-1/4" HEX BUSHING
1
1
6
HH-2984
PRESSURE GAUGE, 0-30# LP
1
1
7
THH-4037
NIPPLE, 1" x 2-1/2" SCH 40
1
1
8
056-2224-6
VALVE, SOLENOID 1" NPT 115V DIN
1
1
9
056-2230-3
VALVE, SOLENOID 1" NPT 115V BYPASS
1
1
10
007-1242-2
NIPPLE, 1" x 2" SCH 40
1
1
11
007-1288-5
ELBOW, 1"-1/2" SCH 40
1
1
12
HH-2029
NIPPLE, 1/2" x 1-1/2" SCH 40
2
2
13
HH-1453
TEE, 1/2" x 1/2" x 1/2" SCH 40
1
1
14
HH-7013
SWITCH SCREW-IN VAPOR HIGH-LIMIT
1
1
15
THH-4071
ELBOW 1/2"- 90° SCH 40
1
1
16
TFC-0023-50
REGULATOR, 1/2" NPT - CSA 50 PSI
1
1
17
D07-0019
NIPPLE, 1/2" x 1-1/2" SCH 80
2
2
18
HH-4846
TEE, 1/2" x 1/2" x 1/4" SCH 80
1
1
19
031-1008-7
PRESSURE RELIEF VALVE 300 PSI
1
1
20
HH-1251
STRAINER, 1/2" “Y” SCH 80
1
1
21
HH-1932
ELBOW, 1/2" PIPE - 1/2" FLARE BRASS
1
1
22
TF-1227
PIPE TRAIN BRACKET FOR 36 AND 42"
1
1
23
326-1047-9
U-BOLT 5/16-18 x 1-3/8 x 2-3/16
3
3
24
401-5503-8
PLUMBING MTG BRACKET
1
1
25
401-5255-5
PLUMBING MTG BASE BRKT
1
1
26
HH-4847
ELBOW, 1/2"-90° SHC 80
2
*
27
D01-2217
VAPORIZER SUPPORT PLATE BLACK
1
1
28
410-1783-1-B
VAPORIZER ADJUSTING WELDMENT 1/2"
1
*
29
D01-2220
VAPORIZER ADJUSTING WELDMENT 3/4"
*
1
30
007-1930-2
REDUCER, BELL 3/4" - 1/2" SCH 80
*
2
31
HH-1082
ELBOW, 1/2"-90°STREET SCH 80
*
2
REF #
PART #
DESCRIPTION
ORIFICE SIZE
*
THF-3058
ORIFICE FOR 40" FANS W/15 HP MOTORS
.344"
*
THF-3247
ORIFICE FOR 42" FANS W/20 HP MOTORS
.375"
*
THF-3249
ORIFICE FOR 42" FANS W/25 HP MOTORS
.391"
*
THF-3059
ORIFICE FOR 42" FANS W/30 HP MOTORS
.438"
*
THF-3252
ORIFICE FOR 42" FANS W/40 HP MOTORS
.453"
* NOT SHOWN
