Page 29
2. Auger and Meter Roll Drive Trains
PNEG-545 100 Series Portable Dryer 29
Top Auger Drive (Continued)
Figure 2D Top Auger Motor and Motor Mount
REF #
PART #
DESCRIPTION
QTY
108T
112
114
116
118
119
122
126
1
D01-0453
TOP AUGER BELTGUARD BODY
1
1
1
1
1
1
1
1
2
D52-0001
SHEAVE 2 GR 16" GRIPBELT
1
1
1
1
1
1
1
1
3
D32-0019
BUSHING Q1 - 1-1/2" SPLIT TAPER
1
1
1
1
1
1
1
1
4
D01-0464
BELT-V BX97
2
2
2
2
2
2
2
2
5
D03-0174
SHEAVE 2.5 D x 7/8" BORE
1
1
5
2818-2
SHEAVE 2 GR 3.35 D x 1-1/8" BORE
1
1
1
5
D62-0003
SHEAVE 2 GR 4.25 D x 1-3/8"
1
1
1
6
D01-0155
MOUNTING BRACKET - BELT GUARD SPCR
1
1
1
1
1
1
1
1
7
D01-0424
DRYER TOP HAND HOLD
1
1
1
1
1
1
1
1
*8
D03-1107
MOTOR 2 HP 1 PH 1800 RPM
1
1
8
200-3
MOTOR 2 HP 3 PH 1800 RPM
1
1
*8
D03-1109
MOTOR 5 HP 1 PH 1800 RPM
1
1
1
8
500-3
MOTOR 5 HP 3 PH 1800 RPM
1
1
1
*8
D03-1010
MOTOR 7.5 HP 1 PH 1800 RPM
1
8
712-3
MOTOR 7.5 HP 3 PH 1800 RPM
1
1
8
1000-3
MOTOR 10 HP 3 PH 1800 RPM
1
9
D01-0173
TOP MOTOR MOUNT WELDMENT
1
1
1
1
1
1
1
1
10
D01-0465
TURNBUCKLE 1/2" x 6" PLATED
1
1
1
1
1
1
1
1
11
D01-0170
ANCHOR BRACKET-MOTOR MOUNT
1
1
1
1
1
1
1
1
12
D01-0452-Y
TOP AUGER BELTGUARD COVER OCHR
1
1
1
1
1
1
1
1
13
DC-971
DECAL, BELT DRIVE WARNING
2
2
2
2
2
2
2
2
14
FH-4429-1
LATCH
3
3
3
3
3
3
3
3
REF # 8, PART # D03-1109 AND D03-1010 ARE SINGLE PHASE MOTORS
7
8
9
10
11
