Page 16
16
PNEG-545 100 Series Portable Dryer
1. Main Structure Assembly
Clean-Out Doors (Continued)
Figure 1M Center Handle Mechanisms (This Handle Mechanism Straddles the Center Cross Channels)
Clean-Out Doors Parts List
REF #
PART #
DESCRIPTION
QTY
108T
112
114
116
118
120
122
126
1
D01-0264
PIVOT ROD 25.188"
2
2
2
2
2
2
2
2
1a
D31-0162
PIVOT ROD 49.625"
1
1
1
1
1
2
2
2
D01-0296
LINKAGE BAR WELDMENT
2
4
4
4
4
4
6
6
3
D01-0261
LINKAGE BAR, 37" LONG
2
2
2
2
2
2
2
2
3a
D01-0293
LINKAGE BAR, 30" LONG
2
2
2
2
2
4
4
4
D01-0294
CLEAN-OUT DOOR HANDLE
2
4
4
4
4
4
6
6
5
S-4378
PLASTIC GRIP
2
4
4
4
4
4
6
6
6
S-248
WASHER, FLAT 3/8 USS ZN
4
8
8
8
8
8
12
12
7
S-7241
COTTER PIN, 1/8 x 1-1/4
4
8
8
8
8
8
12
12
8a
D51-0077
CLEAN-OUT DOOR ASSEMBLY 3-COLUMN
2
1
1
9
D21-0005
CLEAN-OUT DOOR, 67"
1 PER ASSEMBLY
10
D21-0012
SUPPORT CHANNEL, CLEAN-OUT DOOR
1 PER ASSEMBLY
11
D01-0308
CLEAN-OUT DOOR HINGE
2 PER ASSEMBLY
8b
D11-0032
CLEAN-OUT DOOR ASSEMBLY 4-COLUMN
1
1
2
1
2
2
9
D31-0021
CLEAN-OUT DOOR, 91"
1 PER ASSEMBLY
10
D31-0130
SUPPORT CHANNEL, CLEAN-OUT DOOR
1 PER ASSEMBLY
11
D01-0308
CLEAN-OUT DOOR HINGE
2 PER ASSEMBLY
8c
D01-0349
CLEAN-OUT DOOR ASSEMBLY 5-COLUMN
1
2
1
9
D01-0180
CLEAN-OUT DOOR, 115"
1 PER ASSEMBLY
10
D01-0307
SUPPORT CHANNEL, CLEAN-OUT DOOR
1 PER ASSEMBLY
11
D01-0308
CLEAN-OUT DOOR HINGE
3 PER ASSEMBLY
12
D01-0175
HINGE BRACKET
2
4
4
5
5
6
6
7
13
D01-0181
CLEAN-OUT EXTENSION, 119.75"
2
4
2
13
D31-0023
CLEAN-OUT EXTENSION, 90.75"
2
2
4
2
4
4
13
D21-0006
CLEAN-OUT EXTENSION, 66.75"
4
2
2
14
D01-0299
PIVOT ROD BRACKET
3
3
3
3
3
6
6
5
11
3a
14
2
3a
14
14
4
1a
