1. Main Structure Assembly
PNEG-545 100 Series Portable Dryer 5
Frame Assembly (Continued)
Figure 1B Right Front Corner of Frame
Figure 1C Left Rear Corner of Frame
4a
NOTE: The right front corner is shown in the photo. For left front corner all parts are the same
except for the hitch bracket (use 1a for the left side) and the frame rail (use 4a for the left side).
1 1a
2
4
3
NOTE: The left rear corner is shown in the photo. For right rear corner all parts are the same except
for the frame rail (use 4 for the right side).
2
3
5
4 4a
