18' Autoflow
Grain Systems, Inc. Assumption, Ill.
REV. 11-20-96
HI-LO THERMOSTAT
The Hi-Lo Thermostat is designed for use with the GSI Top Dry Crop Dryer units. It comes with one (1)
thermostat which is adjustable and cycles the heater from high to low flame. the Hi-Lo Thermostat also comes
with a thermometer for monitoring the plenum temperature.
Inatallation:
1.
Locate mounting position of thermostat as shown in Figure #58. Important: Do not mount the
thermostat between the fans on a 2-fan system.
2.
Use template supplied to cut hole in sidewall.
3.
Apply rope caulk to sides and top of plastic housing. Leave bottom open to let moisture escape.
4.
Secure housing to sidewall using self-drilling screws supplied. Be careful not to overtighten.
Overtightening may cause the housing to crack.
5.
This completes installation instructiones for the Hi-Lo Thermostat. For operating instructions, see
instructions in the Crop Dryer Unit Owner's Manual.
Figure #58
