Figure #38, Figure #39, Fan entrance sheets – Grain Systems PNEG-366 User Manual
Page 32
Grain Systems, Inc. Assumption, Ill.
32
18' Autoflow
Field cut notch
Round corners to
prevent tearing
Roof Ladder
Support Channel
Top Leveling Band
Figure #38
Note: Field cut rounded notches
in the outer leveling band(s) where
the two roof support channels
hang from the roof ribs.
Figure #39
TD-100680
36" Fan Entrance Sheet
TD-100099
Fan Adapter (28")
TD-100098
Fan Adapter (24")
TD-100206
Fan Adapter-Blank
24" thru 36" Fans
REV. 11-20-96
FAN ENTRANCE SHEETS
