84
Print Direction
Print Direction defines Portrait relative to the direction of feed:

Head First (factory default) makes Portrait elements feed first.

Foot First makes Portrait elements feed last (see Figure 20).
Feed
Inv. Portrait
Po rtr ait
Lan
d
sc
ap
e
In
v. L
an
d
sc
ap
e
Print Direction = Head First
Portrait
Inv. P ort rait
In
v. L
an
d
sc
ap
e
Lan
d
sc
ap
e
Print Direction = Foot First
Figure 20. Orientation versus Print Direction
Character Group and Character Sets
This menu item selects the character set used by the printer. Changing the Character Group will
automatically change the available selections in the Character Sets menu. Character Groups and
Sets are shown in the in PGL Character Sets section on page 119.
Select SFCC
You can specify which decimal code (1-255) will be used as the Special Function Control Code
(SFCC). The SFCC denotes that the following data is a PGL command.
The range is 1-255, and the factory default is 126.
Host Form Length
Determines how the Label Length (see Media/Sensor Tab, page 71) is affected upon receiving an
EXECUTE command.

Enable (factory default). The physical label length will change to match the form length
(specified in CREATE command). The physical label size remains at the new setting until
another EXECUTE command is received, or the Media/Sensor settings are changed.

Var. Length. The physical label length is the longest print element defined in CREATE
mode, including both static and dynamic elements, plus the setting of Var Form Adjust
with CREATE;NAME;0.

Var. Dynamic Len. The physical label length will change to the longest print element
defined in the form, including the dynamic element in EXECUTE mode and the static
element in CREATE mode, plus the setting of Var Form Adjust with CREATE;NAME;0.

Disable. Forms printed in EXECUTE mode do not change the physical label size.
Therefore, the size of the form (defined in CREATE mode) must fit within the current label
dimensions, or errors may occur.
