ZL0103-0B Page 3 of 26 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 10131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
E50B1, E50C2, E50C3
TM
Table of Contents
Dimensions 4
Data Outputs 4
Product Diagram 5
Display Screen Diagram 5
Installation 6
Supported System Types 7
Wiring Symbols 7
Wiring 8
Control Power 9
Quick Setup Instructions 10
Solid State Output 11
User Interface Menu Abbreviations Defined 11
User Interface for Data Configuration 12
Alert/Reset Information 13
User Interface for Setup 14
RS-485 Communications (E50C3 Only) 16
Data Logging (E50C3 Only) 16
Modbus Point Map Overview 17
Standard Modbus Default Settings 17
Modbus Point Map Overview 18
Modbus Point Map 19
Troubleshooting 26
China RoHS Compliance Information (EFUP Table) 26
