Installation Guide
Power Monitoring
E50B1, E50C2, E50C3
TM
E50C2 FDS E50C3 L
og
E50xx REG.
R/W NV Format Units Scale Range Description
• • 311/312 R NV Float kVARh Reactive Energy Consumption
• • 313/314 R Float kVA Apparent Power, Phase A
• • 315/316 R Float kVA Apparent Power, Phase B
• • 317/318 R Float kVA Apparent Power, Phase C
• • 319/320 R Float kVAR Reactive Power, Phase A
• • 321/322 R Float kVAR Reactive Power, Phase B
• • 323/324 R Float kVAR Reactive Power, Phase C
• • 325/326 R Float kW Total Real Power Present Demand
• • 327/328 R Float kVAR Total Reactive Power Present Demand
• • 329/330 R NV Float kVA Total Apparent Power Present Demand
• • 331/332 R NV Float kW Total Real Power Max Demand
• • 333/334 R NV Float kVAR Total Reactive Power Max Demand
• • 335/336 R NV Float kVA Total Apparent Power Max Demand
• • 337/338* R Float
0 -
4294967040 Pulse Counter 1 (Real Energy)
Contact Closure Counters. Valid for
both Pulse inputs and outputs. E50xx
counts are shown in (). See register
144 (Energy per Pulse) for the Wh per
pulse count. Clear via register 129.
Inputs are user defined. These values
are derived from the 32 bit integer
counter and will roll over to 0 when
the integer counters do.
• • 339/340* R Float
0 -
4294967040
• • 341/342* R NV Float kWh Real Energy Consumption, Phase A
clear via reset register • • 343/344* R NV Float kWh Real Energy Consumption, Phase B
• • 345/346* R NV Float kWh Real Energy Consumption, Phase C
Logging Interface
• 8000 R NV Newest Logged Data Entry
5760 entries total (60 days at a 15 minute sub-interval) (to) (to)
• 13760 R NV Oldest Logged Data Entry
Invalid or Quiet Not A Number (QNAN) conditions are indicated by 0x8000 (negative zero) for 16 bit integers and 0x7FC00000 for 32 bit floating point numbers.
Floating point numbers are encoded per the IEEE 754 32-bit specifications.
* Points 337/338 through 345/346 are not available on units with firmware versions 1.018 or earlier.
Modbus Point Map (cont.)
