Gas sampling and conditioning technology 9-0.2-ME
(C) Consumable parts, (R) Recommended spare parts
and (S) Spare parts
recommended quantity CG
beeing in operation [years]
(a.r. = as required)
C/R/S 1 2 3
95 A 9003 Catalyst cartridge CG2-C C a.r. a.r. a.r.
95 A 9004 Catalyst cartridge CG-2-SS C a.r. a.r. a.r.
95 A 9070 O-ring set for CG2 S - - 1
95 A 9040 Control board compl. CG - 230V S - - 1
95 A 9040a Control board compl. CG - 115V S - - 1
95 A 9057 Heater CG2, 230V 50/60Hz S - - 1
95 A 9057a Heater CG2, 115V 50/60Hz S - - 1
01 B 8401 Temperature controller CG, Typ 70304 S - - 1
90 K 6045 Fan 80 x 80, 24V C - 1 2
05 V 1060 Male connector G1/4“-DN4/6
PVDF R 2 4 4
05 V 6600 Ferrule 4/6 PV R 5 10 15
05 V 6605 Union nut M10-4/6 PV R 4 8 10
21 APPENDIX

Wiring plan CG-2M,
Drawing No. : 2224-5.04.0

Wiring plan CG-2H-W,
Drawing No. : 2224-5.04.5

Wiring plan CG-2MH-W,
Drawing No. : 2224-5.04.4
For further product documentation, please see our internet catalogue:
www.mc-techgroup.com
