13
Gas sampling and gas conditioning technology 6-6.1-ME
14 MAINTENANCE
In case of correct use the heated connector works maintenance free.
The safety instructions specific to the plant and process are to be consulted prior to any repair work!
W A R N I N G !
Aggressive condensate is possible.
Wear protective glasses and proper protective clothing!
High surface temperatures!
Touching the filter surface can cause serious burns!
Wear protective gloves and protect the filter of unauthorized
access!
Prior to carrying out maintenance work on electrical parts, mains
voltage should be disconnected from all poles!
This also applies to any external control circuits, which may be
connected.
15 SPARE PARTS LIST
Electrically heated connectors T.-H1 and V.-H1
(C) Consumables, (R) recommended spare parts, and
(S) spare parts
Recommended quantity
For operating period
[years]
C/R/S 1 2 3
90 P 5015 Heating cartridge , 230V/50Hz, 100W, length: 50mm S a.t.r. a.t.r. a.t.r.
90 P 5016 Heating cartridge , 115V/60Hz, 100W, length: 50mm S a.t.r. a.t.r. a.t.r.
90 P 5020 Thermostat (0-180°C), with over-temperature limiter
and low-temperature alarm S a.t.r. a.t.r. a.t.r.
a.t.r. = according to requirements
16 APPENDIX
Further product documentation can be seen and downloaded from our homepage:
www.mc-techgroup.com
