26
Gas sampling and conditioning technology 10-1.1-ME
18 SPARE PART LIST
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and are not binding.
Combustion Air Conditioning BA ...
(C) Consumable parts, (R) recommended spare parts, (S) spare parts
recommended quantity for
BA... being in operation
[years]
(b.d. = by demand)
V/E/T 1 2 3
96 A 0010 Adsorbtion cartridge compl. filled
incl. 2 x O-Ring seals 90 F 0050
C b.d. b.d. b.d.
96 A 0065 Pt/Pd-Catalyst cartridge BA..
incl. O-Ring seals:
2 x inner seals 90 E 1000
2 x outer seals 90 S 2040
C b.d. b.d. b.d.
Swing piston compressor M1 (version BA-P4)
96 A 0070 Spare part set consisting of:
- 4 x Valve plate for NPK09
- 3 x Seal for NPK09
- 3 x O-ring
- 3 x Seal lipp for NPK09
- 1 x Cylinder
C 1 2 3
Air filter Fl1 (version BA-P4)
90 F 0016 Fine-filter element F-0,1GF, glass fibre 0,1µ C 1 2 3
Particle condensate filter YA1
Pre-filter unit R - 1 1
Main-filter unit R - - 1
19 APPENDIX

Circuit diagram BA... with controller 703/70304

Circuit diagram BA... with controller TM48
More product documentation is available on our Internet catalogue:
www.mc-techgroup.com
