8
Gas sampling and gas conditioning technology 4-3.1-ME
8 TECHNICAL DATA
Gas Conditioning Type SS-5 SS-5/3
Part No. version 230V 50Hz
Part No. version 115V 60Hz 03G5000
03G5000a
03G5500
03G5500a
Sample outlet dew point range of adjustment: +2 °C … +15 °C, factory setting: +5 °C
Dew point stability at const. conditions: < ±0,1°C
Sample inlet temperature **max. 80°C*
optional: **max. 180°C with stainless steel bulkhead union
Sample inlet dew point **max. +80°C
Gas flow rate **max. 150Nl/h **max. 350Nl/h
Ambient temperature **+5°C up to +40°C
Storage temperature -25°C up to +65°C
Pressure 0,7bar up to 1,4bar abs.*
Total cooling power max. 50kJ/h max. 90kJ/h
Number of gas inlets 1
Number of gas outlets 1*
optional: max. 4
Medium connections tube connections 4/6 mm
Material of parts beeing in contact
with the medium stainless steel, glass, PPH, PVC, PVDF, PTFE, Novoprene
®
optional: Viton for gas sample line
Ready for operation approx. 10 min.
Mains power supply 230V 50Hz ± 10% or 115V 60Hz ± 10%
Power consumption max. 240VA
Option temperature controller and heated sample line:
230V max. 1620VA, 115V max. 930VA
Fuse protection 4A T , 5mmx20mm
with option temperature controller and heated sample line:
10AT, 5mmx20mm
Electrical connection Terminals 4mm 2
Case protection IP20 (EN 60529)
Casing portable aluminium case
Casing dimensions (H x W x D) 385mm x 515mm x 190mm
Weight approx. 18,5kg approx. 20,0kg
Electrical equipment standard EN 61010
Options
Temperature controller:
range of control: 0°C-200°C
Input :
PT100
230V, max. 6A Part No. 01G9055
115V, max. 6A Part No. 01G9055a
Flow meter FM40 (optionally),
max. 4 7-70 l/h air, Part No. 01G9070
15-150 l/h air, Part No. 01G9075
25-250 l/h air, Part No. 01G9080
50-500 l/h air, Part No. 01G9085
Liquid alarm LA 1S/1.4 Part No. 01G9035
5-way-ball valve 60750 Part No. 01G9045
PPH=Polypropylene, PTFE=Polytetrafluoroethylene (Teflon®), PVC=Polyvinyl chloride, PVDF=Polyvinylidenfluoride
* Standard
** Maximum values in technical datas must be rated in consideration of total cooling capacity at 25 °C ambient
temperature and an outlet dew point of 5 °C.
