Gas sampling and gas conditioning technology 3-3.0EX-ME
21 SPARE PARTS LIST
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and they are not binding.
Electric gas cooler ECM-ExII
(C) Consumable parts
(R) Recommended spare parts
(S) Spare parts
Recommended quantity being in
operation [years]
Part No. Indication C/R/S 1 2 3
93 K 0140 ECP-3000 G Jet-Stream heat exchanger
material: Borosilicate glass
connections gas: GL18-6mm
condensate: GL 25-12mm E 1
1
1
93 K 0160 ECP-3000 SS Jet-Stream heat exchanger
material: SS 316
connections gas: G 1/4“i
condensat:e: G 3/8“i E 1 1 1
93 K 0170 ECP-3000 PV Jet-Stream heat exchanger
material: PVDF (Polyvinylidenfluorid)
connections gas: G 1/4“i
condensate: G 3/8“i E1 1 1 1
97 K 0100 ECM-2G Jet-Stream heat exchanger
material: Borosilicate glass
connections gas: GL18-6mm
condensate: GL 25-12mm E 1 1 1
97 K 0110 ECM-2PV Jet-Stream heat exchanger
material: PVDF (Polyvinylidenfluorid)
connections gas: 6mm tube
condensate: G 3/8“i E 1 1 1
97 K 0115 ECM-2SS Jet-Stream heat exchanger
material: SS 316
connections gas: 6mm tube
condensate: G 3/8“i E 1 1 1
90 K 0115 EC-thermal conductivity paste 50g (-40°C bis 140°C) E 1 1 2
90 K 0035 Fan ECP 230V, 50Hz V - - 1
93 K 0040X PT-100 temperature sensor for ECM V - - 1
90 K 7005 Cooling unit, complete with compressor, vaporiser
and condensor for ECM
cooling medium: R134A, power: 230V, 50Hz E - - -
97 K 0010 ECM transformer 115V/230V, ... 230VA E - - -
01 B 8365 Electronical PID temperature controller for ECM-Ex T - - 1
Peristaltic pump SR25.2
(C) Consumable parts
(R) Recommended spare parts
(S) Spare parts
Recommended quantity being in
operation [years]
Part No. Indication V/E/T 1 2 3
90 P 1007 Hose set  SR25.1
with PVDF-tube connectors 4/6mm, standard V 1 2 4
90 P 1020 Driver SR25, complete T - 1 1
90 P 1010 1 set (4 pcs) contact springs SR25 for driver E 1 2 2
90 P 1045 Contact pulleys SR25 PVDF  for driver T 2 4 4
90 P 1050 Conveying belt SR25.1  T - 1 2
90 P 1025 S-bolt  SR25.1 T - - 1
01 P 1300 Peristaltic pump SR25.2, complete 230V/115V, 50/60Hz E - - 1
90 P 1031 Heat peristaltic pump SR25, complete without tube set, motor and
gears T - - 1
