Gas sampling and gas conditioning technology 10-5.1-ME
21 OPTION LOW TEMPERATURE ALARM
The heated protective housing PAS can be controlled by a low temperature alarm contact.
The sensor is fixed to the ceiling of the inner oven. The controller of this thermostat is installed in the
top of the oven under the top cover.
The range of temperature setting is from 100
– 180°C. The standard controller setting is at +150°C.
The contact is closed during normal operation and opens when the temperature decreases <150°C.
The contact rating is 230V AC, 16A.
To change controller setting, unscrew the 4 screws at the top of the rear side of the housing and take
the cover of. Put the knob of the controller to the desired temperature on the scale. Close the cover.
22
ANNEXE
Wiring plan low temperature alarm drawing no.: 22842010
Further product documentation can be seen and downloaded from our home page:
www.mc-techgroup.com
