11
Gas sampling and gas conditioning technology 10-5.1-ME
13.2 MATERIAL QUALITY
The external casing and working chamber is out of stainless steel 1.4301 which features high strength,
optimum hygienic properties and corrosion resistance against many (not all) chemicals (warning
against e.g. chlorine compounds). The oven load has to be checked carefully for its chemical
compatibility with the above materials.
13.3 ELECTRICAL EQUIPMENT

Operating voltage see label 50/60 Hz

Current rating see label

Protection Class 1, i.e. operating isolation with ground connection to EN 61 010

Protection IP20 to EN 60 529

Interference suppression to EN55011 Class B

Oven protected by a fuse 250V/15A fast blow

Controller protected by an 80 mA fuse (200 mA on 115 V)

When connecting the device to the electrical supply you have to observe any local

regulations which apply (e.g. in Germany DIN VDE 0100 with FI protection circuit)
N O T E !
Any work involving opening up the housing must only be carried out by
skilled staff!
13.4 SUPPLY FAILURE
After a failure of the supply, operation is continued with the same parameter settings.
14
RECEPTION AND STORAGE

Carefully remove the heated protective housing and eventual accessories out of the packing
immediately on arrival and inspect the contents of supply against the packing list;

Check the items for any damage in transit and, if required, inform the shipping insurance company
immediately of the damage found;
N O T E !
The heated protective housing must be stored in a weather-protected frost-
free area!
15
PREPARATION FOR MOUNTING

Before installing the heated protective housing, an easy access for maintenance and space for
adequate ventilation must be considered.

Check whether the mains voltage corresponds to the indication on the type plate.

Check whether the materials in touch with the sample are resistant.
