Example: 3D Dual Link 1SLSM 2x + 1REC+ 1PLAY
The BNC connectors to be used as record and play channels in a 3D Dual Link
configuration 1SLSM 2PH + 1REC + 1 PLAY need to be cabled as shown below:
Rear panels in 2013
Rear panels before 2013
Available SLSM 3x Configurations
The tables below show the available 3D configuration with SLSM 3 Phase cameras on an
XTnano server. They show the link assignment at the level of the codec module of a V3 X
board.
IN4/OUT3 IN3/OUT4 IN2/OUT5 IN1/OUT6
#REC
SLSM
3x
#REC #PLAY
Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link
1 0 1 PLAY
1A PLAY
1B REC
1,3A REC
1,3B REC
1,2A REC
1,2B REC
1,1A REC
1,1B
72 3. Multicam Configuration
EVS Broadcast Equipment S.A. Issue 11.02.A July 2013
