3.2. Supported Configurations
3.2.1. General Information on Supported
Configurations
Overview on Supported Configuration Types
An XTnano server, equipped with V3X boards, supports the following configurations
types:
• standard SD/HD configurations
• standard SD/HD XREC configurations (using secondary links for independent
recorders)
• SLSM SD/HD configurations
• SLSM SD/HD XREC configurations
• 3D configurations
• SLSM 3D configurations
An XTnano server, equipped with COHX boards, supports the following configurations
types:
• standard SD/HD configurations
• SLSM SD/HD configurations
Note
The feature 'Mix on one channel' for play channels is not available.
Number of Record and Play Channels
The number of record and play channels for a given configuration is defined in the
Channels tab, in the Base settings. See section "Base Settings" on page 91.
The number of channels available may differ depending on the following elements:
• The video codec board installed:
◦ V3X
◦ COHX
• The configurations running on the XTnano server:
◦ SportLight mode, when it is controlled by the Nano Remote Panel
◦ Server mode, when it is controlled by industry-standard protocols such as Sony
BVW75, VDCP, Odetics, or DD35.
