Inputs
Description Number of logical record channels in the given configuration.
The partition of the disk storage between these channels, and
the advanced audio settings are automatically adapted to the
number of record channels.
Values The number of supported channels depends on the chassis,
and the mode, as well as the codec board. The values are
given for the V3X codec boards:
• On XTnano: 1-4 (SportLight), 0-4 (Server)
See section "General Information on Supported
Configurations" on page 52 for more information on number of
record channels and on supported configurations.
Outputs
Description Number of logical play channels in the given configuration.
Values • On XTnano: 1-2 (SportLight), 0-4 (Server)
See section "General Information on Supported
Configurations" on page 52 for more information on number of
record channels and on supported configurations.
Base Config.
Description Mode the EVS server is working in.
The base configurations available depend on the server type,
and on the valid license codes.
Values • Server:
mode where the EVS server can be controlled by one or
more of the following protocols: Sony BVW75, VDCP,
Odetics, DD35, but not from the Multicam production
screens.
• SportLight :
mode where the EVS server is controlled by the nano
Remote Panel, or from the Multicam production screens.
Default value SportLight
