3.2.4. SLSM Configurations
Introduction
SLSM Principles
This section details the available 2 phase and 3 phase SLSM configurations in SD/HD on
XTnano servers.
In SLSM 2 Phase configurations, one SLSM recorder accounts for one logical channel,
but corresponds to two physical channels.
In SLSM 3 Phase configurations, one SLSM recorder accounts for one logical channel,
but corresponds to three physical channels.
Overview on Configurations
The tables below show the available SLSM 2 Phase and SLSM 3 Phase configurations in
SD/HD with an XTnano server, and how the BNC connectors should be cabled.
The XREC configurations, presented at the end of the tables, make use of the secondary
link of the codec module of a record channel as an independent recorder. See section
"Channel Assignment in XREC Configurations" on page 57.
The XREC license (code 30) only available with an XTnano server equipped with V3X
boards.
Note
Specific SLSM configurations for and 3D dual link configurations, only available
with V3X boards, are presented in the section "3D SLSM Configurations" on
page 71.
