• in both modes, the three areas of the Clip Infos pane used to enter clip metadata can
be expanded or collapsed by clicking a small arrow: General, Keywords, Metadata
Profiles.
• in Player mode, the Clip List pane and the Associated Logs pane can be hidden or
shown in a reduced or enlarged size by clicking one of the split boxes
• in Player mode, most of the panes can be enlarged or reduced by moving the
intersection line between them.
2.2. Recorder Channels Selection Area
Purpose
This area is only available in Live mode.
It displays all the recorder channels from the EVS video servers which are available on the
XNet network. They correspond to different camera angles.
This area is used to select all the recorder channels from which logs will be relevant when
users log a media, and clips will be generated.
Selecting the Preview Recorder
The field on the left is used to select the recorder channel which will be set as preview
recorder.
The preview recorder provides the timecode displayed in the Live tab. It will also be the
first angle selected to view an event when an IPDirector operator loads a log.
To select the preview recorder, right-click the field and select a recorder channel from the
contextual menu:
As soon as a preview recorder has been selected, its name is shown as title tab.
To clear the selection of preview recorder, right-click the Preview Recorder field and
select None.
