Prestige 334 User’s Guide
241 Chapter 25 Network Address Translation (NAT)
Figure 116 Menu 15.1.1 First Set
25.3.1.2 Ordering Your Rules
Ordering your rules is important because the Prestige applies the rules in the order that you
specify. When a rule matches the current packet, the Prestige takes the corresponding action
and the remaining rules are ignored. If there are any empty rules before your new configured
rule, your configured rule will be pushed up by that number of empty rules. For example, if
you have already configured rules 1 to 6 in your current set and now you configure rule
number 9. In the set summary screen, the new rule will be rule 7, not 9.
Menu 15.1.1 - Address Mapping Rules
Set Name= NAT_SET
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- -------------- --------------- --------------- ------
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Action= Edit Select Rule=
Press ENTER to Confirm or ESC to Cancel:
Note: If the Set Name field is left blank, the entire set will be
deleted.
Note: The Type, Local and Global Start/End IPs are configured
in menu 15.1.1.1 (described later) and the values are displayed
here
