Prestige 334 User’s Guide
Chapter 22 Internet Access 222
Figure 101 Internet Access Setup (PPPoE)
The following table contains instructions about the new fields when you choose PPPoE in the
Encapsulation field in menu 4.
If you need a PPPoE service name to identify and reach the PPPoE server, please go to menu
11 and enter the PPPoE service name provided to you in the Service Name field.
22.5 Basic Setup Complete
Well done! You have successfully connected, installed and set up your Prestige to operate on
your network as well as access the Internet.
You may deactivate the firewall in menu 21.2 or via the Prestige embedded web configurator.
You may also define additional firewall rules or modify existing ones but please exercise
extreme caution in doing so. See the chapters on firewall for more information on the firewall.
Menu 4 - Internet Access Setup
ISP's Name= MyISP
Encapsulation= PPPoE
Service Type= N/A
My Login=
My Password= ********
Retype to Confirm= ********
Idle Timeout= 100
IP Address Assignment= Dynamic
IP Address= N/A
IP Subnet Mask= N/A
Gateway IP Address= N/A
Network Address Translation= SUA Only
Press ENTER to Confirm or ESC to Cancel:
Table 73 New Fields in Menu 4 (PPPoE) screen
FIELD DESCRIPTION
Encapsulation Press [SPACE BAR] and then press [ENTER] to choose PPPoE. The
encapsulation method influences your choices in the IP Address field.
Idle Timeout This value specifies the time in seconds that elapses before the Prestige
automatically disconnects from the PPPoE server.
Note: When the firewall is activated, the default policy allows all
communications to the Internet that originate from the LAN, and
blocks all traffic to the LAN that originates from the Internet.
