Prestige 334 User’s Guide
Chapter 23 Remote Node Configuration 228
Figure 104 Menu 11.1 Remote Node Profile for PPTP Encapsulation
The next table shows how to configure fields in menu 11.1 not previously discussed.
23.3 Edit IP
Move the cursor to the Edit IP field in menu 11.1, then press [SPACE BAR] to select Yes.
Press [ENTER]
to open Menu 11.3 - Remote Node Network Layer Options.
Menu 11.1 - Remote Node Profile
Rem Node Name= MyISP Route= IP
Active= Yes
Apply Alias= None
Encapsulation= PPTP Edit IP= No
Service Type= Standard Telco Option:
Service Name= N/A Allocated Budget(min)= 0
Outgoing: Period(hr)= 0
My Login= Schedules=
My Password= ******** Nailed-Up Connection= No
Retype to Confirm= ********
Authen= CHAP/PAP
PPTP: Session Options:
My IP Addr= Edit Filter Sets= No
My IP Mask= Idle Timeout(sec)= 100
Server IP Addr=
Connection ID/Name= Edit Traffic Redirect= No
Press ENTER to Confirm or ESC to Cancel:
Table 76 Menu 11.1 Remote Node Profile for PPTP Encapsulation
FIELD DESCRIPTION
Encapsulation Press [SPACE BAR] and then [ENTER] to select PPTP. You must also go to menu
11.3 to check the IP Address setting once you have selected the encapsulation
method.
My IP Addr Enter the IP address of the WAN Ethernet port.
My IP Mask Enter the subnet mask of the WAN Ethernet port.
Server IP Addr Enter the IP address of the ANT modem.
Connection ID/
Name
Enter the connection ID or connection name in the ANT. It must follow the “c:id” and
“n:name” format.
This field is optional and depends on the requirements of your DSL modem.
