Prestige 334 User’s Guide
315 Chapter 34 VPN/IPSec Setup
Figure 177 Menu 27 VPN/IPSec Setup
34.2 IPSec Summary Screen
Type 1 in menu 27 and then press [ENTER] to display Menu 27.1 IPSec Summary. This is a
summary read-only menu of your IPSec rules (tunnels). Edit or create an IPSec rule by
selecting an index number and then configuring the associated submenus.
Figure 178 Menu 27
Menu 27 - VPN/IPSec Setup
1. IPSec Summary
2. SA Monitor
Enter Menu Selection Number:
Menu 27.1 – IPSec Summary
#
-
001
002
003
Name
Key Mgt
---------
Taiwan
IKE
zw50
IKE
China
IKE
A
-
Y
N
N
Local Addr Start
Remote Addr Start
-----------------
-
192.168.1.35
172.16.2.40
1.1.1.1
4.4.4.4
192.168.1.40
N/A - Local Addr End
- Remote Addr End
-------------------
-
192.168.1.38
172.16.2.46
1.1.1.1
255.255.0.0
192.168.1.42
N/A
Encap
------
Tunnel
Tunnel
Tunnel
IPSec Algorithm
Secure GW Addr
------------------
ESP DES MD5
193.81.13.2
AH SHA1
zw50test.zyxel.
ESP DES MD5
0.0.0.0
Select Command= NoneSelect Rule= N/A
Press ENTER to Confirm or ESC to Cancel:
Table 104 Menu 27.1 IPSec Summary
FIELD DESCRIPTION
# This is the VPN policy index number.
Name This field displays the unique identification name for this VPN rule. The name may be
up to 32 characters long but only 10 characters will be displayed here.
A Y signifies that this VPN rule is active.
